– PORTS: 1x USB3.2 (G2) TYPE C | 2x USB3.2 (G1) | HD AUDIO
– DRIVE: 2x 3.5″ / 2.5″, 2x 2.5″
– CPU HEATSINK HEIGHT: 162mm
– PSU LENGTH: 200mm
– VGA CARD LENGTH: 340mm
– SUPPORT UP TO 240mm RADIATOR
– 1x INWIN MERCURY FAN (AM120S) INCLUDED
Model
A5
Model Number
IW-CS-A5BLK-1AM120S
IW-CS-A5WHI-1AM120S
Colors
Black, White
Case Type
Mid Tower
Materials
SECC, Tempered Glass, PC-ABS
M/B Compatibility
12″ x 11″ E-ATX, ATX, Micro-ATX, Mini-ITX
Expansion Slots
7 x PCI-E
Maximum Compatibility
GPU Length: 340 mm
CPU Heatsink Height:
162 mm
I/O Ports
1 x USB 3.2 Gen 2×2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo
(CTIA – SPK/Mic)
Internal Drive Bays
2 x 3.5″ / 2.5″
2 x 2.5″
Thermal Solution Compatibility
Air Cooling Fans:
Top: 2 x 120 mm
Rear: 1 x 120 mm
Bottom: 2 x 120 mm
(1 InWin Mercury AM120S Fan Included)
Water Cooling Radiator:
Top: 1 x 240 mm
Power Supply Compatibility
PSII: ATX12V
– Length between 140 – 200 mm
(PSUs longer than 170 mm will need to build with GPUs 280 mm or shorter)
Product Dimensions
(L x W x H) 399 x 215 x 407 mm
15.7 x 8.5 x 16″
Package Dimensions
(L x W x H) 473 x 277 x 483 mm
18.6 x 10.9 x 19″
Net Weight
5.86 kg / 12.92 lbs
Gross Weight
6.94 kg / 15.30 lbs
