Description

Intel Denverton-based Atom C3538 Quad-Core CPU

8GB DDR4-2133 SO-DIMM – 30% faster than DDR3

Dual Intel 10-Gigabit Ethernet ports – Supports up to 20 Gbps under Link Aggregation

Dual Realtek 2.5-Gigabit Ethernet ports – Supports up to 5 Gbps under Link Aggregation

Supports 10x 3½” SATA hard drives and SSDs

Dual M.2 NVMe SSD ports for fast caching

Supports an extra 144 TB with the AS6004U

Thumbscrews for easy M.2 SSD installation

Supports Wake on LAN and Wake on WAN

Efficient cooling design

Best in class three year warranty

Dual 10 and 2.5 Gigabit ports. Faster than ever.

The all new Lockerstor series of NAS feature dual Intel 10-Gigabit Ethernet ports as well as dual Realtek 2.5-Gigabit Ethernet ports. With a managed switch that supports multiple speeds, take advantage of up to 20 gbps of speed with both 10-Gigabit ports or up to 5 gbps on both 2.5-Gigabit ports.

SSD Cache

The recently updated ADM features an updated Linux Kernel and additional performance enhancements. The Lockerstor series introduce M.2 PCIe NVMe SSD caching increasing performance.

1. Lockerstor NVMe SSD caching increases performance by up to 60%.
2. Lockerstor NVMe SSD caching is faster than if all bays were filled with SATA SSDs while remaining cheaper.

With dual 10-Gigabit Ethernet, bottlenecks on NVMe SSDs have been lifted, making the Lockerstor one of the fastest NAS devices ever.

Ten Bay with M.2 SSD Cache flexible storage

The AS6510T is a cost-effective large capacity NAS designed for enterprise environments.The AS6510T supports online capacity expansion, allowing for the flexible purchase of enterprise storage equipment. When your budget and storage requirements are smaller, you can purchase a smaller number of hard disks. Additional disks can be purchased as your storage requirements grow. Combined with ASUSTOR’s MyArchive storage technology, this allows you to effectively achieve unlimited storage.

Easily upgrade memory by opening the chassis.

The Lockerstor comes with 8 Gigabytes of DDR4 RAM and can be upgraded up to 64GB. DDR4 RAM provides up to 30% greater performance than DDR3 while also lowering energy requirements by 40%.

24/7 Reliability and Durability

All ASUSTOR NAS are designed for and are suitable for 24/7 use. ASUSTOR NAS devices have also undergone rigorous tests, such as drop tests and burn tests to test durability in extreme conditions. Heatsinks were added to sensitive components to dissipate heat, helping to maintain the longevity of the device.



CPU

CPU Model
Intel ATOM C3538

CPU Architecture
x64 64-bit

CPU Frequency
Quad-Core 2.1GHz

Memory

Memory
8GB SO-DIMM DDR4

Memory Module Pre-installed
8GB (1x 8GB)

Memory Expandable up to
64GB (2x 32GB)

Flash Memory
4GB eMMC

Storage

Drive Bays
10

M.2 Drive Slots
2

Compatible Drive Type

  • 3.5″ SATA HDD
  • 2.5″ SATA HDD
  • 2.5″ SATA SSD
  • M.2 2280 NVMe
  • M.2 2280 SATA 3
  • M.2 2260 SATA 3
  • M.2 2242 SATA 3

Maximum Drive Bays with Expansion Unit
18

External Ports

Expansion
2x USB 3.2 Gen 1

Network
2x 10 Gigabit Ethernet(10G/1G);
2x 2.5 Gigabit Ethernet (2.5G/1G/100M)

HDMI Output
N/A

Others

System Fan
2x 120mm

Power Supply Unit / Adapter
250W x1

Input Power Voltage
100V to 240V AC

Certification
FCC, CE, VCCI, BSMI, C-TICK

Warranty
3 Years

Operation

Power Consumption
76.8W (Operation);
41.1W (Disk Hibernation);

Noise Level
22dB (HDD idle)

Operation Temperature
0°C~40°C (32°F~104°F)

Humidity
5% to 95% RH

Size and Weight

Size
215.5(H) x 293(W) x 230(D) mm

Weight
6.4 (kg) / 14.1 (lb)
