Quad-Core 10 nm Intel Celeron N5105 CPU – 31% more performance over Gemini Lake
Superfast 2.5-Gigabit Ethernet ports
Flexible PCIe slot for M.2 SSDs
Supports PCIe 3.0 SSDs for up to twice the performance of PCIe 2.0.
Uses DDR4-2933 with 40% more performance
USB 3.2 Gen2 ports – 10Gbps speed
Enjoy, download, upload and stream content with 4K transcoding
Increased ventilation for SSDs
Supports Wake on LAN and Wake on WAN
Powered by the Latest 10 nm Intel Jasper Lake Celeron Quad-Core Processors
The Lockerstor Gen2 comes with Intel’s newest Quad-Core Celeron CPUs. The N5105 comes with Intel 10 nm technology and is up to 31% faster than Gemini Lake SoCs. The Celeron N5105 is clocked at 2.0 GHz with 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.
Four M.2 Slots – Have Your Cake and Eat it Too
The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs.
Four M.2 SSD slots bring a number of custom scenarios to your NAS when it comes to accelerating your storage.
Keeping Cool
With up to four SSDs, a considerable amount of heat can be generated. With extra ventilation, the Lockerstor Gen2 ensures that all components in your NAS receive cooling.
Tool-Free M.2 SSD Installation
Uses latches instead of screws for easier installation.
2.5 + 2.5 = Extreme Speeds
The Lockerstor Gen2 has two 2.5GbE ports which more than doubles the performance of Gigabit Ethernet devices. But that’s not all, with the recent introduction of support for SMB Multichannel, your NAS will be able to combine the speed of multiple Ethernet ports for speeds way beyond 2.5-Gigabit Ethernet.
CPU
CPU Model
Intel Celeron N5105
CPU Architecture
x64 64-bit
CPU Frequency
Quad-Core 2.0GHz (burst up 2.90 GHz)
Memory
Memory
4GB SO-DIMM DDR4
Memory Module Pre-installed
4GB (1x 4GB)
Total Memory Slots
2
Memory Expandable up to
16GB (2x 8GB)
Support mixed capacity
Youtube
Flash Memory
8GB eMMC
Storage
Drive Bays
2
M.2 Drive Slots
4
Compatible Drive Type
3.5″ SATA HDD
2.5″ SATA HDD
2.5″ SATA SSD
M.2 2280 NVMe
Maximum Drive Bays with Expansion Unit
10
External Ports
Expansion
2x USB 3.2 Gen 2×1
Network
2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
HDMI Output
1x HDMI 2.0b
Others
System Fan
1x 70mm
Power Supply Unit / Adapter
65W x1
Input Power Voltage
100V to 240V AC
Certification
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Warranty
3 Years
Operation
Power Consumption
21 W (Operation);
13.5 W (Disk Hibernation);
0.79 W (Sleep Mode)
Noise Level
17.7dB (HDD idle)
Operation Temperature
0°C~40°C (32°F~104°F)
Humidity
5% to 95% RH
Size and Weight
Size
163.5 (H) x 108 (W) x 230 (D) mm
Weight
2 kg / 4.4 lb
