Description

Enthusiast-grade NAS with two, four or six bays

The LOCKERSTOR Gen2 series of NAS devices come with the all-new Quad-Core Intel Celeron N5105 CPU featuring Intel 10 nm technology. Intel’s Jasper Lake Celeron CPUs bring up to 31% extra performance over the previous generation of Celeron CPUs. The LOCKERSTOR Gen2 is flexible. Install up to four M.2 SSDs or a 10-Gigabit Ethernet card in the available PCI Express slot for maximum performance.
The LOCKERSTOR Gen2 uses DDR4-2933 and super-fast 2.5-Gigabit Ethernet which makes content creation even easier than ever before.

Unleashed Potential

Supports Premiere Pro & Final Cut Pro

Easily collaborate with anyone, anywhere.

Adobe Creative Cloud data backup and version control

Stream YouTube and/or Twitch videos with rebroadcasting and live recording functionality

CPU

Intel’s newest N5105 Quad-Core CPU comes with Intel 10 nm technology and up to 31% increased performance over Gemini Lake SoCs. The N5105 is clocked at 2.0 GHz with a boost of up to 2.9 GHz, enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.



CPU

CPU Model
Intel Celeron N5105

CPU Architecture
x64 64-bit

CPU Frequency
Quad-Core 2.0GHz (burst up 2.90 GHz)

Memory

Memory
4GB SO-DIMM DDR4

Memory Module Pre-installed
4GB (1x 4GB)

Total Memory Slots
2

Memory Expandable up to
16GB (2x 8GB)

Support mixed capacity

Youtube

Flash Memory
8GB eMMC

Storage

Drive Bays
4

M.2 Drive Slots
4

Compatible Drive Type
3.5″ SATA HDD
2.5″ SATA HDD
2.5″ SATA SSD
M.2 2280 NVMe

Maximum Drive Bays with Expansion Unit
12

External Ports

Expansion
2x USB 3.2 Gen 2×1

Network
2x 2.5 Gigabit Ethernet (2.5G/1G/100M)

PCIe Expansion Slots
1x for optional expansion 10 GbE card

HDMI Output
1x HDMI 2.0b

Others

System Fan
1x 120mm

Power Supply Unit / Adapter
90W x1

Input Power Voltage
100V to 240V AC

Certification
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC

Warranty
3 Years

Operation

Power Consumption
35 W (Operation);
17.3 W (Disk Hibernation);
0.88 W (Sleep Mode)

Noise Level
17.6dB (HDD idle)

Operation Temperature
0°C~40°C (32°F~104°F)

Humidity
5% to 95% RH

Size and Weight

Size
185.5(H) x 170(W) x 230(D) mm

Weight
2.94 kg / 6.48 lb
