Windows + Mac + Linux cross-platform file sharing
Windows ACL support combined with Windows AD infrastructure enhances management efficiency for business applications
Military grade AES 256-bit encryption
10GbE Ethernet card and memory expansion slots allow for further expansion as the need arises
New disk tray locks ensure that hard disks will not be accidentally ejected during operation
SMB 2/3 support increases Windows networking performance by 30%-50%
A Surge in Data Transfer Performance
ADM 2.6 supports SMB 2.0 which reduces the burden of network traffic on the NAS while simultaneously providing greater data transfer capacity.In the ASUSTOR testing environment, SMB 2.0 was found to increase Windows networking performance by 30%-50%*. SMB 2.0 also significantly increases the number of concurrent Windows client connections and simultaneously open files, making ADM 2.6 even more suitable for large-scale Microsoft network environments.
Advanced File Permissions Management – Windows ACL
For IT professionals, file permissions configuration is a very important topic, especially in enterprise environments. Because the native Linux system file permission mechanisms are different than those in Windows, in the past, IT professionals had to create a separate set of permissions for files stored on NAS servers. This also limited the number of permission configuration options that were available to them.
In order to help IT professionals simplify their work, ASUSTOR has comprehensively integrated Windows ACL into ADM. Windows ACL provides a set of 13 different permissions settings, allowing administrators to configure permissions for individual files and folders that can be applied to different groups and users. Windows ACL permissions can be configured from within ADM’s File Explorer or Microsoft Windows Explorer allowing administrators to easily manage permissions using familiar methods.
Optimized Cooling Design
When there is a high load on the NAS, the CPU will begin to heat up, affecting the stability of the system. A common way of dealing with this is to lower the CPU frequency which will then cause the temperature to decrease. However, this will also lower the overall performance of the system.
ASUSTOR’s 70 Series devices utilize fans with wide speed ranges combined with a smart speed control mechanism that allows the CPU to maintain a controlled operating temperature even under high loads. Under most circumstances the fans will operate at a low speed, conserving energy. When the system load and temperature increases, the fans will automatically increase their speed to cool the CPU without it having to lower its frequency. This allows the NAS to maintain stability and high performance even under high loads.
CPU
CPU Model
Intel® Core i3
CPU Architecture
x64 64-bit
CPU Frequency
Dual-Core 3.5GHz
Memory
Memory
2GB SO-DIMM DDR3
Memory Module Pre-installed
2GB (1x 2GB)
Total Memory Slots
2
Memory Expandable up to
16GB (2x 8GB)
Support mixed capacity
Youtube
Flash Memory
1GB DOM
Storage
Drive Bays
8
Compatible Drive Type
3.5″ SATA HDD
2.5″ SATA HDD
2.5″ SATA SSD
Maximum Drive Bays with Expansion Unit
20
External Ports
Expansion
USB 3.0 x 3, USB2.0 x 2, eSATA x 2
Network
2x Gigabit Ethernet
HDMI Output
1x HDMI 1.4a
Others
System Fan
2x 120mm
Power Supply Unit / Adapter
350W x1
Input Power Voltage
100V to 240V AC
Certification
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC
Warranty
3 Years
Operation
80.3W (Operation)
43.7W (Disk Hibernation)
1.97W (Sleep Mode)
Noise Level
27.6dB (HDD idle)
Operation Temperature
0°C~40°C (32°F~104°F)
Humidity
5% to 95% RH
Size and Weight
Size
215.5(H) x 293(W) x 230(D) mm
Weight
7.2 kg / 15.87 lb
