- Intel Xeon 9th generation Quad-Core CPU
- 8GB of server-grade DDR4-2666 ECC memory (Max 64GB, 32GB x 2)
- Dual M.2 NVMe SSD ports for fast caching
- Complete iSCSI/IP-SAN and NFS support. VMware, Citrix and Hyper-V ready. Supports virtualization and Docker apps
- Brings the smoothest work experience with 10-Gigabit Ethernet, triple 2.5-Gigabit ports and USB 3.2 Gen2 ports.
- Supports Wake on LAN (2.5-Gigabit ports )
CPU
CPU Model Intel Xeon E-2224
CPU Architecture x64 64-bit
CPU Frequency Quad-Core 3.4GHz up to 4.6GHz
Memory
Memory 8GB DDR4 ECC SO-DIMM
Memory Module Pre-installed 8GB (1x 8GB)
Total Memory Slots 2
Memory Expandable up to 64GB (2x 32GB)
Support mixed capacity
Flash Memory 8GB USB DOM
Storage
Drive Bays 10
M.2 Drive Slots 2
Compatible Drive Type
3.5″ SATA HDD
2.5″ SATA HDD
2.5″ SATA SSD
M.2 2280 NVMe
M.2 2280 SATA 3
M.2 2260 SATA 3
M.2 2242 SATA 3
Maximum Drive Bays with Expansion Unit 22
Supports Hot Swappable Drives
External Ports
Expansion 1x Front USB 3.2 Gen 1, 2x Rear USB 3.2 Gen 2 (10Gbps)
Network 1x 10 Gigabit Ethernet (10G/5G/2.5G/1G/100M);
3x 2.5 Gigabit Ethernet (2.5G/1G/100M)
Multimedia Output N/A
Others
System Fan 2x 120mm
LCD Panel
Power Supply Unit / Adapter 350W x1
Input Power Voltage 100V to 240V AC
Certification FCC, CE, VCCI, BSMI, C-TICK
Warranty 5 Years
Operation
Power Consumption 78.7W (Operation);
40.1W (Disk Hibernation);
5.8 W (Sleep Mode)
Noise Level 22dB (HDD idle)
Operation Temperature 0°C~40°C (32°F~104°F)
Humidity 5% to 95% RH
Size and Weight
Size 215.5(H) x 293(W) x 230(D) mm
Weight 7.1 (kg) / 15.62 (lb)
AS7110T
