All New Hardware – Same Great Case

2.5-Gigabit Ethernet – More than twice the performance of Gigabit

Realtek RTD1296 Quad-Core CPU at 1.4Ghz

DDR4 RAM – 40% more efficient

High performance, 4K decoding

Supports Wake on LAN and Wake on WAN

Brand-New ADM 4.0

ADM 4.0 is here and brings a whole host of intuitive design changes to ADM OS. The upgraded UI brings a new aesthetically-pleasing dark mode that helps to save and preserve OLED displays. ADM 4.0 introduces a new login page that contains a variety of customizable elements, a more convenient and easier-to-use quick search feature and new custom themes. Under the hood, ADM 4.0 brings improvements to performance, compatibility and security as the new version of OpenSSL plugs vulnerabilities found in previous versions, increasing security while efficiency improvements bring better performance.

Rose Gold Coloring

The all-new Rose Gold Logo is elegant and distinct, enabling easy distinction between ASUSTOR NAS models.

Realtek Quad-Core CPU and DDR4 RAM

The Drivestor 2 and Drivestor 4 are equipped with a Realtek RTD1296 1.4GHz Quad-Core 64-bit CPU. Transcode, stream and play multimedia in 4K, transfer files and easily multitask with the Drivestor series. The Drivestor handles multitasking with ease by utilizing its 1 GB of DDR4 memory ensuring that virtually any task on an ASUSTOR NAS is executed smoothly.

Efficient and Powerful

The Drivestor 2 and 4 are ASUSTOR’s highest value devices ever. Transcode 10-bit 4K H.265 media with hardware decoding easily that enables unbelievably smooth video playback in LooksGood.

CPU

CPU Model
Realtek RTD1296

CPU Architecture
ARM64 64-bit

CPU Frequency
Quad-Core 1.4GHz

Memory

Memory
1GB DDR4

Memory Expandable up to
not expandable

Flash Memory
8GB eMMC

Storage

Drive Bays
2

Compatible Drive Type
3.5″ SATA HDD

Maximum Drive Bays with Expansion Unit
12

External Ports

Expansion
2x USB 3.2 Gen 1

Network
1x 2.5 Gigabit Ethernet (2.5G/1G/100M)

HDMI Output
N/A

Others

System Fan
1x 120mm

Power Supply Unit / Adapter
90W x1

Input Power Voltage
100V to 240V AC

Certification
FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC

Warranty
3 Years

Operation

Power Consumption
22.8W (Operation) 9.41W (Disk Hibernation);

Noise Level
19.7dB (HDD idle)

Operation Temperature
0°C~40°C (32°F~104°F)

Humidity
5% to 95% RH

Size and Weight

Size
165(H) x 164(W) x 218(D) mm

Weight
1.57 kg / 3.45 lbs
