80 PLUS® Gold certified
87-92% high efficiency performance @ 20-100% load
Dust Free Rotation Tech. (patented)
Dust Free Rotation technology enables the fan to instantly blow away the dust to prolong the lifespan
D.F. switch
D.F. switch design allows users to activate DFR self-cleaning function at anytime during operation
Smart Airflow Control (SAC) design
SAC design keeps PSU fan spinning at almost inaudible 400rpm within 70% system load to provide the optimal silent experience
Twister Bearing fan (patented)
Twister Bearing Technology ensures ultra silent cooling and long lifetime of fan (160,000 hours MTBF)
100% 105°C Japanese electrolytic capacitors
Highest component standards for maximum durability and stability
Full modular design
Full modular cable design facilitates system installation and cable management
MODEL
ERF850EWT
80 PLUS EFFICIENCY
GOLD
MODULAR
Full modular
CABLE TYPE
Black flat
TOTAL POWER (W)
850
INPUT VOLTAGE (V)
100-240
INPUT CURRENT (A)
12/6
INPUT FREQUENCY (HZ)
47-63
FAN SIZE (MM)
135
OPERATING TEMPERATURE (°C)
50
MTBF (HOURS)
>100K
PROTECTION
OCP, OVP, UVP, OPP, OTP, SCP, SIP
DIMENSION (D X W X H), (MM)
160 x 150 x 86
