Flexible drive bays configuration for ODD, 2.5″ and 3.5″ HDD
Supports easy-swap rear fan x 2 for upgrade
Compatible with standard PS2 or mini-redundant power supply
Expandable storage option with InWin storage kit
GPU holder and adjustable card retainer supporting 350mm dual-slot PCIe cards x 4
Optional rear fan module for GPU
Convertible to tower with chassis stands (optional)
Lockable front door for data security
Tool-free cover for easy installation and quick maintenance
Industry Standard
EIA-RS310D
M/B Form Factor
ATX (12″ x 9.6″), CEB (12″ x 10.5″), EEB (12″ x 13″)
*The bottom 5.25 drive bay space should be reserved for the EEB motherboard installation
Drive Bay
External: 5.25″ x 3, 3.5″ x 1
Internal: 3.5″ x 4, 2.5″ x 1
Power Supply Supports:
• PS2, up to 600W
• Optional mini-redundant up to 500W
Indicator
Power status, HDD, LAN activity LEDs
Front Control Panel
Power switch, System reset, USB 2.0 x 2
Chassis Security
Intrusion switch (optional)
Cooling Fan
Supports:
• 80 x 25mm PWM front fan x 2, 4500RPM
• 80 x 25mm PWM rear fan x 2 (optional), 4200RPM
• 80 x 25mm PWM rear fan x 2 (optional), 4500RPM
Expansion Slot
Full-height PCI slot x 8
Material
• Material: SGCC
• Thickness: 1.2mm
Rail Kit
Supports 28″ tool-less & ball-bearing slide rails
Product Dimensions (DxWxH; Chassis Only)
525x 430 x 174.8mm
(20.7″ x 16.9″ x 6.9″)
Package Dimensions (DxWxH)
696 x 610 x 310mm
Weight (Chassis Only)
• Net weight: 12.09kg
• Gross weight: 15.37kg
Cubic Feet
4.65
Container Information
Single packing with pallets:
• 20′: 144pcs
• 40′: 300pcs
• 40′ HQ: 350pcs
