ATX Black (up to 12” x10.7”), USB 3.0 A type x2 + USB2.0 A type x2 + HD Audio,RGB, 140mm front fan x3 + standard 140mm rear fan x1
Model No.
SST-PM01B-RGB (black + RGB LED + tempered glass window)
SST-PM01C-RGB (matte black + RGB LED + tempered glass window)
SST-PM01W-RGB (white + RGB LED + tempered glass window)
Material
Plastic outer shell, steel body, tempered glass side panel
Motherboard
ATX (up to 12″ x 10.7″), Micro ATX
Drive bay
Internal
2.5″ or 3.5″ x 4, 2.5″ x 5
Cooling system
Front
3 x 120mm / 140mm fan slot (includes 3 x 140mm fan + RGB LED fan guards)
Rear
1 x 120mm / 140mm fan slot (includes 1 x 140mm fan)
Top
3 x 120mm fan slot or 2 x 140mm fan slot
Radiator support
Front
2 x 120mm ; 1 x 240mm / 280mm / 360mm
Rear
1 x 120mm / 140mm
Top
2 x 120mm ; 1 x 240mm / 280mm / 360mm*
Limitation of CPU cooler
180mm
Expansion slot
7
Limitation of expansion card
Support graphics card up to 16.5″ (419mm), width restriction – 6.88″ (174mm)
Power supply
Standard PS2 (ATX)
Limitation of PSU
240mm
Front I/O port
USB 2.0 x 2
USB 3.0 x 2
Audio x 1
MIC x 1
Dimension
220mm (W) x 571mm (H) x 560mm (D), 70.3 Liters
8.66″ (W) x 22.48″ (H) x 22.05″ (D), 70.3 Liters
Net weight
10.1kg
Extra
Built-in RGB LED controller**
