SSI-CEB, ATX, Micro-ATX Casing
Model No.
SST-RV04B (black)
SST-RV04B-W (black + window)
Material
Reinforced plastic outer shell, steel body
Color
black
Motherboard
SSI-EEB*, SSI-CEB, Extended ATX, ATX, Micro-ATX
Drive bay
External
5.25″ x 2
Internal
3.5″ x 7 (2 hot-swap) , 2.5″ x 4
Cooling system
Front
2 x Air Penetrator AP181 180mm intake fan 600/900/1200rpm, 18/25/34dBA
Rear
1 x 120mm fan slot (option)
Radiator support
Front
120mm x 3 / 140mm x 2 / 180mm x 2
Rear
120mm x 1
Limitation of CPU cooler
165mm
Expansion slot
8
Limitation of expansion card
Compatible up to 13.3″ (337mm) long, width restriction-6.69″ (169mm)
Power supply
1 x optional standard PS2 (ATX)
Limitation of PSU
180mm
Front I/O port
USB 3.0 x 2
audio x 1
MIC x 1
Dimension
219mm (W) x 581mm (H) x 497mm (D), 63.2 liters
8.62″ (W) x 22.87″ (H) x 19.57″ (D), 63.2 liters
Net weight
10.9 kg
Extra
Support two Kensington locks
