SST-ST50F-ES230

SGD 63.30

Availability:Out Of Stock

Description
  • High efficiency with 80 PLUS certification
  • 24/7 continuous power output with 40℃ operating temperature
  • Class-leading single +12V rail
  • Active PFC Circuitry
  • PCI-E 8pin and PCI-E 6pin connector support
  • Silent running 120mm fan with 18dBA

The Strider Essential series is a line of power supplies designed with high affordability and great performance. They have 80 PLUS certification with maximum efficiency of up to 85% under 230V. Equipped with powerful single +12V rail and quiet running fan, they also provide stable performance with minimum noise. For longevity, they are based on proven design and built with quality components to support 24/7 operation at up to 40 degrees Celsius. Even high-end systems with powerful graphics cards can be powered easily by Strider Essential PSUs standard 8pin/6pin PCI-E connectors, making them an outstanding choice for those seeking best value and performance for their money.

Model No.
SST-ST50F-ES230

Max. DC Output
500W

Power density
277W per liter

Load Range (V2.0)
+3.3V +5V +12V +5VSB -12V
Max.(Amps) 18A 17A 38A 2.5A 0.3A
Peak (Amps) / / / / /
Min.(Amps) 0A 0A 0A 0A 0A
Range (%) ±5% ±5% ±5% ±5% ±10%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV

Load Range (V1.0)

+3.3V +5V +12V +5VSB -12V
Max.(Amps) 24A 20A 34A 2.5A 0.3A
Peak (Amps) / / / / /
Min.(Amps) 0.1A 0.2A 0.1A 0A 0A
Range (%) ±5% ±5% ±5% ±5% ±10%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV

combined +3.3, +5V
110W (V2.0)
120W (V1.0)

combined +12V
456W (V2.0)
400W (V1.0)

Input Voltage
180 ~ 264Vrms (V2.0)
207 ~ 253Vrms (V1.0)

Input Frequency Range
47Hz ~ 63Hz

PFC
Active PFC.（PF>0.9 at Full Load）

Efficiency
82%~85% @ 20% ~ 100% loading

MTBF
100,000 hours

Operating temperature
0°C ~ 40°C

Protection
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Under voltage protection (V1.0)

Connectors
V2.0
1 x 24 / 20-Pin motherboard connector（500mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）
2 x 8 / 6-Pin PCIE connector（”500mm / 150mm” x 2）
4 x SATA connector（”500mm / 150mm” x 2）
2 x 4-Pin Peripheral connector（500mm / 150mm / 150mm / 150mm）
1 x 4-Pin Peripheral connector（500mm / 150mm / 150mm）
1 x 4-Pin Floppy connector（500mm / 150mm / 150mm / 150mm）V1.0
1 x 24 Pin motherboard connector（450mm）
1 x 8-Pin EPS12V connector（550mm）
1 x 4-Pin ATX12V connector（550mm / 150mm）
2 x 8 / 6-Pin PCIE connector（400mm / 150mm）
6 x SATA connector（700mm / 150mm / 150mm）
3 x 4-Pin Peripheral connector （400mm / 150mm / 150mm）
1 x 4-Pin Floppy connector（400mm / 150mm / 150mm / 150mm）

Cooling System
Silent 120mm fan

Noise Level
18 dBA minimum

Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91″ (W) x 3.39″ (H) x 5.51″ (D)

Weight 1.31kg (V2.0)
1.7kg (V1.0)

Certification
80 PLUS

Other
GPU Support list
Compatible with ATX12V v2.4
